NMR Facility

At present the NMR Facility is equipped with three solution state Spectrometers (AVI 400MHz, AVIII 400MHz and AVIII500MHz) capable of a wide range of NMR experiments and techniques. All 3 spectrometers have BACS60 autosampler, which allows for fully automated analysis of up to 60 samples at a time.

NMR spectroscopy services are also provided for other Schools within the University, other academic institutions and industrial clients.

Bruker AVI 400MHz Spectrometer

Magnet – Bruker Ultrasheild 400 MHz
Console - Bruker AvanceProbe - quadruple probe (QNP, for detection of 1H, 13C, 19F and 31P) with z-axis pulsed field gradients
Automation - 60 slot BACS sample changer
Variable Temperature Unit Range - from -150oC to +150oC
Workstation & Software – Linux / TopSpin 2.1

Bruker AVIII 400MHz Spectrometer

Magnet – Bruker Ultrasheild 400 MHz

Console -  Bruker Avance  IIIProbe - BBFO - 5 mm probe with the inner coil tuneable to observe or decouple 19F or any nucleus in the range from 31P to 15N and the outer coil is tuned for either 1H decoupling or observation

Automation - 60 slot BACS sample changer

Variable Temperature Unit Range - from -150oC to +150oC

Workstation & Software – Linux / TopSpin 2.1

Bruker AVIII 500MHz Spectrometer

Magnet – Bruker Ultrasheild 500 MHz
Console - Bruker Avance III
Probe - BBFO - 5 mm probe with the inner coil tuneable to observe or decouple 19F or any nucleus in the range from 31P to 15N and the outer coil is tuned for either 1H decoupling or observation

QXI -5mm inverse triple resonance probe optimized for 1H observation and 13C, 31P and 15N decoupling

Automation - 60 slot BACS sample changer

Variable Temperature Unit Range - from -150oC to +180oC

Workstation & Software – Linux / TopSpin 2.1

The NMR Systems are very well specified above and the NMR facility can offer routine 1H, 13C, 19F and 31P spectra run completely in automation. More demanding multi-pulse experiments can be performed following discussion, as required, with our expert experienced staff.

The NMR can also offer dynamic, variable temperature experiments in the range of minus 100degrees centigrade to plus 100 degrees centigrade.

To submit a query or to discuss how we may be able to assist you contact Dr David Adam.
