HMS Medusa - Plan 2

Lower deck plan of HMS Medusa, dated 1800.  Scale is 1:48.

HMS Medusa was designed by William Rule in 1796.  See HMS Medusa for more details of the ship's specifications.

Lower deck plan of HMS Medusa, dated 1800.  Scale is 1:48.  (Image courtesy of the National Maritime Musuem, Plan Ref: ZAZ2968, Image Ref: J5894.  Copyright reserved.)

View larger image

(Image courtesy of the National Maritime Museum, Plan Ref: ZAZ2968, Image Ref: J5894.  Copyright reserved.)
